Thermal Ribbon
Z110 Resin Enhanced Wax
Product features
Z110 Resin Enhanced Wax Ribbon produces crisp, rotated barcodes and dark, durable images. Z110 can be used as a “plug and play” alternative to other industry leading resin enhanced wax formulations. Z110 offers our best all-around performance when considering optical density, image durability, print quality and wide receiver material latitude.
Recommended substrates
100%
Coated Papers
100%
Tags
100%
Rough Papers
100%
Films
100%
Thermal Transfer Papers
80%
Synthetics
Printing characteristics
- Ink color
- Black
- Color density
- ≥ 1.8 (test on X-Rite tester)
- Abrasion resistance
- ≥ 20 times (200g weight, test on coated papers)
Recommended printing conditions
Printer mode
Flat head
Print speed
≤ 6 ips
Desktop printers, Industrial printers
Depending on the type of printer and print carrier, the print quality and image durability may vary.
Technical specifications
Back coat
PET base flim
Ink layer
- Base film
- BOPET
- Total ribbon thickness (μm)
- 7.1±0.5
- Storage conditions
- -5°C~40°C, 20%~85% Relative Humidity
- Base film thickness (μm)
- 4.5±0.2
- Ink melting point
- 85°C
- Shelf life
- 1 year
Certificates and Reports
RoHS 2.0
REACH
ISO9001/14001/45001
MSDS
ISEGA
Application scenario
Commercial retail
Storage
Logistics
Nursery gardens and flowers
Fixed assets
Clothing tag
Pre packaging
Production lines
Z201 Premium Wax/Resin
Product features
Z201 is a UL-recognized Premium Wax/Resin Ribbon and delivers superior image durability on a wide variety of labels and tag materials. Along with increased abrasion and heat resistance, Z201 also provides excellent print darkness and high definition characters and images. Z201 prints up to 10ips utilizing less print head energy and offers “plug and play” compatibility with industry leading premium wax/resin ribbons.
Recommended substrates
100%
Coated Papers
80%
Tags
80%
Rough Papers
80%
Films
60%
Thermal Transfer Papers
Printing characteristics
- Ink color
- Black
- Color density
- ≥ 1.6 (test on X-Rite tester)
- Abrasion resistance
- ≥150 times (200g weight, test on coated papers)
Recommended printing conditions
Printer mode
Flat head
Print speed
≤ 10 ips
Desktop printers, Industrial printers
Depending on the type of printer and print carrier, the print quality and image durability may vary.
Technical specifications
Back layer
PET base film
Release layer
Ink layer
Adhesive layer
- Base film
- BOPET
- Total ribbon thickness (μm)
- 7.0±0.5
- Storage conditions
- -5°C~40°C, 20%~85% Relative Humidity
- Base film thickness (μm)
- 4.5±0.2
- Ink melting point
- 80°C
- Shelf life
- 1 year
Certificates and Reports
RoHS 2.0
REACH
ISO9001/14001/45001
MSDS
ISEGA
UL
Application scenario
Commercial retail
Storage
Logistics
Nursery gardens and flowers
Fixed assets
Clothing tag
luggage
Pre packaging
Production lines
Food packaging
Z203 Ultra Wax/Resin
Product features
Z203 is an ultra-performance wax/resin ribbon that bridges the gap between traditional wax/resin and resin formulations. Built on a highly responsive ink system and a thin polyester base, it enables fast, low-energy printing while delivering durability levels typically associated with pure resin ribbons. Z203 performs exceptionally well in applications that require abrasion resistance and stable imaging under cold-chain or refrigerated conditions, making it an ideal solution for medical, pharmaceutical, and electronics labeling where both speed and image integrity are essential.
Recommended substrates
100%
Coated Papers
100%
Tags
80%
PR
100%
PVC
100%
PE
Printing characteristics
- Ink color
- Black
- Color density
- ≥1.7 (test on X-Rite tester)
- Abrasion resistance
- ≥500 times (200g weight, test on coated papers)
- Alcohol resistance
- ≥20 times (500g weight, 95% ethyl alcohol, test on PET labels)
Recommended printing conditions
Printer mode
Flat head
Print speed
≤ 8 ips
14 ips
Desktop printers, Industrial printers
Depending on the type of printer and print carrier, the print quality and image durability may vary.
Technical specifications
Back layer
PET base film
Release layer
Ink layer
Adhesive layer
- Base film
- BOPET
- Total ribbon thickness (μm)
- 5.9±0.5
- Storage conditions
- -5°C~40°C, 20%~85% Relative Humidity
- Base film thickness (μm)
- 3.5±0.2
- Ink melting point
- 95°C
- Shelf life
- 1 year
Certificates and Reports
RoHS 2.0
REACH
ISO9001/14001/45001
MSDS
UL
HALOGEN FREE
Application scenario
Commercial retail
Storage
Logistics
Nursery gardens and flowers
Clothing tag
luggage
Fixed assets
Z309 Economy Resin
Product features
Z309 Economy Resin Ribbon offers our most economical resin thermal transfer printing while providing consistent performance on a wide variety of polyester labels and tag materials. Z309 can be also printed on coated papers. Our proprietary anti-static back coating formulation dissipates static electricity and works to protect and extend the life of the valuable print head.
Recommended substrates
100%
PVC
100%
PET
80%
Coated Papers
60%
PE
60%
PP
40%
Tags
Printing characteristics
- Ink color
- Black
- Color density
- ≥1.5 (test on X-Rite tester)
- Abrasion resistance
- ≥30 times (500g weight, test on CS-10 rub tester)
- Alcohol resistance
- ≥30 times (500g weight, 95% ethyl alcohol, test on PET labels)
Recommended printing conditions
Printer mode
Flat head
Print speed
≤ 8 ips
Desktop printers, Industrial printers
Depending on the type of printer and print carrier, the print quality and image durability may vary.
Technical specifications
Back layer
PET base film
Release layer
Ink layer
Adhesive layer
- Base film
- BOPET
- Total ribbon thickness (μm)
- 6.3±0.5
- Storage conditions
- -5°C~40°C, 20%~85% Relative Humidity
- Base film thickness (μm)
- 4.5±0.2
- Ink melting point
- 90°C
- Shelf life
- 1 year
Certificates and Reports
RoHS 2.0
REACH
ISO9001/14001/45001
MSDS
Application scenario
Commercial retail
Storage
Logistics
Nursery gardens and flowers
Fixed assets
Food packaging
Clothing tag
Z800 Textile Resin
Product features
Z800 Textile Resin Ribbon is a highly durable wash care resin used for garment and textile label printing. It offers excellent print quality and superior resistance to washing, ironing and dry cleaning applications. Highly resistant to heat, water and industrial solvents. Z800 is compatible with a wide variety of nylon materials and synthetic fibers.
Recommended substrates
100%
Satin
100%
Nylon
80%
TPU
Printing characteristics
- Ink color
- Black
- Color density
- Before washing ≥1.0, After washing ≥0.5 (test on Satin PS761 by X-Rite tester)
- Before washing ≥1.1, After washing ≥0.9 (test on Nylon DP661 by X-Rite tester)
- Washing resistance
- ≥Grade 3 (60°C water for washing 8 hours)
- Ironing resistance
- 150°C
Recommended printing conditions
Printer mode
Flat head
Print speed
≤ 4 ips
Desktop printers, Industrial printers
Depending on the type of printer and print carrier, the print quality and image durability may vary.
Technical specifications
Back layer
PET base film
Release layer
Ink layer
Adhesive layer
- Base film
- BOPET
- Total ribbon thickness (μm)
- 6.3±0.5
- Storage conditions
- -5°C~40°C, 20%~85% Relative Humidity
- Base film thickness (μm)
- 4.5±0.2
- Ink melting point
- 90°C
- Shelf life
- 1 year
Certificates and Reports
RoHS 2.0
REACH
ISO9001/14001/45001
MSDS
Application scenario
Luggage
TPU
Tyvek
Textile nylon
Textile satin
Z800PLUS Textile Resin
Product features
Z800PLUS Textile Resin Ribbon is a highly durable wash care resin used for garment and textile label printing. It offers excellent print quality and superior resistance to washing, ironing and dry cleaning applications. Highly resistant to heat, water and industrial solvents. Z800PLUS is compatible with a wide variety of nylon materials, polyester satin, rayon and synthetic fibers.
Recommended substrates
100%
Satin
100%
Nylon
Printing characteristics
- Ink color
- Black
- Color density
- Before washing ≥1.2, After washing ≥0.8 (test on Satin PS761 by X-Rite tester)
- Before washing ≥1.2, After washing ≥1.0 (test on Nylon DP661 by X-Rite tester)
- Washing resistance
- ≥Grade 4 (60°C water for washing 8 hours)
- Ironing resistance
- 150°C
Recommended printing conditions
Printer mode
Flat head
Print speed
≤ 4 ips
Desktop printers, Industrial printers
Depending on the type of printer and print carrier, the print quality and image durability may vary.
Technical specifications
Back layer
PET base film
Release layer
Ink layer
Adhesive layer
- Base film
- BOPET
- Total ribbon thickness (μm)
- 6.3±0.5
- Storage conditions
- -5°C~40°C, 20%~85% Relative Humidity
- Base film thickness (μm)
- 4.5±0.2
- Ink melting point
- 85°C
- Shelf life
- 1 year
Certificates and Reports
RoHS 2.0
REACH
ISO9001/14001/45001
MSDS
Application scenario
Luggage
Textile woven fabrics
Tyvek
Jeans Tag
Textile nylon
Textile satin
